- SUPER RESOLUTION: Vivid IR technology upscales the image to 320x240 from 160x120 for greater detail and clarity. Visual camera with 640x480 resolution enables MSX, which enhances details in real time
- ULTRA CLEAR IMAGES: Patented MSX embosses visual details on the thermal image to create sharper, easier to understand picture
- LASER POINTER: Indicates the size of the measurement area for faster and easier detection
- RUGGED AND RELIABLE: Tough, drop-tested design with an IP54 enclosure that protects the camera from dirt, dust, and oil
- 2-10 Thermal Camera Warranty from FLIR, 2 Years parts and labor coverage on the camera, 10 Years coverage on the detector – the most vital part of the whole camera
The FLIR TG268 is the next generation of the FLIR TG267 and TG275 models. The FLIR TG268 is an all-in-one, non-contact measurement and imaging tool with 60% faster boot-up time (~6 second), higher temperature ranges, that includes Super Resolution technology to enhance image quality. Through Super Resolution, the native resolution of 160 × 120 effectively upscales the image to 320 × 240, delivering greater detail and improved sharpness. Super Resolution ensures clearer thermal images for more precise diagnostics. This advanced imaging capability helps users quickly identify issues, improve decision-making, and conduct more reliable thermal inspections. Accurately measure temperatures up to 400°C (752°F) with a 24:1 spot size ratio and bullseye laser pointer. Ideal for commercial electrical, facility maintenance, and HVAC applications, automotive maintenance and repair technicians. Improve the detail of the native thermal image with Super Resolution, for upscaling images to 320x240. Diagnose problems faster with FLIR-patented MSX image enhancement to add additional detail to aid in troubleshooting. Industrial design with IP54, 2m drop test, 100 Lumen Flashlight and Type K Thermocouple, and quick bootup ensure the tool is ready for all situations, at all times. With the METERLiNK App, add inspection data and images to reports for sharing while in the field. This thermal imaging product has a frame rate of 9Hz and is regulated by the U.S. Department of Commerce (DOC), Export Administration Regulations (EAR) under ECCN 6A993.a, and is subject to certain export restrictions, including prohibitions on sales or transfers involving military end uses or military end users.
- Product Dimensions : 8.2 x 2.6 x 2.5 inches; 1.87 Pounds
- Batteries : 1 Lithium Ion batteries required. (included)
- Date First Available : March 27, 2025
- Manufacturer : FLIR Systems
- Country of Origin : Taiwan
